SENSOR
Type:
CMOS with primary color filter and integrated Shake/Dust
Reduction sensor-movement system
Size: 23.6 x 15.8mm
Color
depth: 8 bits/channel JPG, 12 bits/channel RAW
Effective
pixels: 12.4 MP
Total pixels: 12.9 MP
Recorded
resolutions
Still: 12M (4288x2848), 10M (3936x2624), 6M
(3072x2048), 2M (1728x1152)
Movie (resolution/FPS):
1280x720p / 25 (16:9), 640x480p / 25 (4:3)
Quality levels:
*** Best, **Better, * Good
Dust Removal: Image sensor
movement combined with SP coating (Dust Alert available)
LENS
Type/construction:
PENTAX KAF2 bayonet stainless steel mount
Usable lenses:
PENTAX KAF3, KAF2, KAF, KA (K mount, 35mm screwmount, 645/67
med format lenses useable w adapter and/or restrictions)
SDM
function: Yes
Power zoom function: n/a
FOCUS
SYSTEM
Type:
TTL phase-matching 11 point (9 cross) wide autofocus system
(SAFOX IX)
Focus modes: AF Auto, AF Single (w focus lock),
AF Continuous (available in Action mode including Auto Picture
Action, Kids, Pet, Stage Lighting, Night Snap, P/A/S/M/B/Sv),
Manual
Focus point adjustment: 11 point auto, 5 point auto,
AF point select, center/spot
AF assist: Yes, via dedicated
AF assist lamp with SAFOX IX system
VIEWFINDER
Type:
Pentamirror
Coverage (field of view): Approx
96%
Magnification: Approx 0.85X (w 50mm F1.4 at
infinity)
Standard focusing screen: Natural-Bright-Matte
II
Diopter adjustment: -2.5 to 1.5
Depth of field
preview: Optical & Digital (available via programmable
Green button)
LCD
MONITOR
Type:
3.0” TFT color LCD monitor w adjustable brightness
Resolution: 921,000 dots Wide angle viewable: Yes
FLASH
Type:
Retractable P-TTL auto/manual popup flash
Guide number: 12
(100/m), 16 (200/m)
Coverage: 28mm wide angle (equivalent to
35mm)
Flash modes: On, off, redeye, slow sync, slow sync w
redeye, slow sync w trailing curtain, wireless
Flash
exposure compensation: -2 to 1 EV (1/2 steps)
EXTERNAL
FLASH
Type:
Hot shoe (P-TTL, high speed sync), wireless w PENTAX dedicated
flash
Synchronization speed: 1/180s
STORAGE
MEDIA
Internal
memory: n/a
Removable memory: SD, SDHC
INTERFACES
Ports:
USB 2.0 hi-speed, AV out
Video out: NTSC, PAL
Printer
interfaces: n/a
Infrared Connection: Infrared Connection
in/out (IrSimple)
POWER
SUPPLY
Power
source: Rechargeable Li-Ion battery D-LI109, AA BATTERY HOLDER
D-BH109 (optional) for 4X AA batteries
Recordable images:
Approx 560 (470 w 50% flash, CIPA), Approx 1600 (1000 w 50%
flash, CIPA) with AA Lithium Batteries
Playback time:
Approx. 620 min
Movie recording time: Approx. 25 min (based
on card capacity and resolution setting)
AC adapter
available: Yes
PHYSICAL
SPECS
Body
dimensions (W x H x D): 4.9 x 3.8 x 2.7” Body weight
Without battery or removable memory: 19.2 oz Loaded and ready:
21 oz Construction material(s): Fiber reinforced plastic
polymer covers around a rugged stainless steel chassis Weather
resistant: n/a Operating temperature: 32-104°F
LANGUAGE
SUPPORT
English,
French, German, Spanish, Portuguese, Italian, Dutch, Danish,
Swedish, Finnish, Polish, Czech, Hungarian, Turkish, Greek,
Russian, Korean, Traditional Chinese, Simplified Chinese,
Japanese
STABILIZATION
Type:
Sensor-shift Shake Reduction (4 stops max)
METERING
SYSTEM
Type:
TTL open aperture, 16 segment metering Sensitivity range: EV
1-21.5 (ISO 200, 50mm F1.4) Multi-segment: Yes Center weighted:
Yes Spot: Yes Exposure compensation: +/- 3 EV (1/2 or 1/3
steps) Exposure lock: Yes (available via programmable AF/AE-L
button) Exposure bracketing: Yes, 3 frames, up to +/- 1.5 (1/2
steps) or +/- 1.0 (1/3 steps)
ISO
SENSITIVITY
Auto:
200-12800 (1, 1/2, 1/3 EV steps), up to 1600 in Bulb, expand to
100-25600 Manual: 200-12800 (1, 1/2, 1/3 EV steps), up to 1600
in Bulb, expand to 100-25600
WHITE
BALANCE
Auto
preset modes: Auto, Daylight, Shade, Cloudy, Fluorescent (D, N,
W, L), Tungsten, Flash, CTE Manual mode(s): Yes * WB fine
adjustment available in all modes
SHUTTER
Type:
Electronically controlled, vertical run, focal plane shutter
Shutter speed: 1/6000 to 30 sec, bulb available
CAPTURE
MODES
Mode
selection: Auto Picture (Portrait, Landscape, Macro, Action,
Night Scene Portrait, Standard Flash Off), Picture (Portrait,
Landscape, Macro, Action, Night Scene Portrait, Standard Flash
Off), Scene (Night Scene, Surf & Snow, Food, Sunset, Kids,
Pet, Candlelight, Museum, Stage Lighting [JPG], Night Snap
[JPG], Night Scene HDR [JPG]), Program, Sensitivity Priority,
Shutter Priority, Aperture Priority, Metered Manual, Bulb
(available in Metered Manual), Movie Custom Image Modes:
Bright, Natural, Portrait, Landscape, Vibrant, Muted,
Monochrome. Color modes include gamut radar and fine adjustment
for saturation, hue, key, contrast, sharpness (regular and fine
adj). Monochrome mode includes adjustment for film filter
effects (green, yellow, orange, red, magenta, blue, cyan,
infrared), toning (sepia warm/cool), key, contrast, sharpness
(regular and fine adj). Cross Processing mode available for
creative random effect generation. Green simplified mode
available: n/a P/A/S/M/B: P, A, S, M, B (in Metered Manual), Sv
(Sensitivity Priority) Date stamp: n/a Digital filters
(capture): Toy Camera, High Contrast, Soft, Starburst, Retro,
Color Extract (6), Fisheye, Custom (8) Data record: Folder name
(standard/date)
DRIVE
MODES
Mode
selection: Single, Continuous (Hi, Lo), Self Timer (12s, 2s),
Remote (0s, 3s), Auto Bracket, HDR Capture (+3, 0, -3 w 2 blend
settings), Multi-Exposure Continuous FPS: Approx 6.0 FPS
(Continuous Hi: 25 JPG, 12 RAW), 2 FPS (Continuous Lo:
unlimited JPG, 36 RAW) Self-timer: Yes (12s, 2s) Remote
control: Yes (infrared, 0s, 3s)
PLAYBACK
MODES
Mode
selection: One Shot (no data, basic data, full data, color
channel histogram), Multi Image Display (4, 9, 16, 36 or 81
thumbnails), Calendar Filmstrip, Folder, Magnification (quick
zoom available), Select & Delete, Movie Playback (no data,
basic data, full data), Bright/Dark Indication Mode pallet:
Image Rotation, Digital Filter, Resize, Cropping, Slideshow,
Image Comparison, RAW Development, Index Print, Protect, DPOF
Magnification: Up to 16X, scrollable Digital filters
(playback): Toy Camera, Retro, High Contrast, Extract Color
(6), Watercolor, Sketch, Pastel, Miniature, Base Parameter Adj,
Monochrome (filter effects, toning), Color (6), Soft,
Starburst, Fisheye, Slim, HDR, Posterization, Custom Filter
FILE
FORMATS
Still:
RAW (PEF, DNG), JPG (EXIF 2.21), DCF 2.0 (design rule for
camera file system), DPOF, Print Image Matching III Movie
(compression): AVI (motion JPG)
CUSTOM
FUNCTIONS
Functions
available: 22
COMPUTER
REQUIREMENTS
*For
device connectivity. Bundled software requirements may vary.
Windows: Windows XP/Vista/7, USB 2.0 port Mac: MacOS-X
10.3-10.5, USB 2.0 port
|
